NEWTOP PAPER CUP MACHINE FOR ESPRESSO CUPS
|
1. Mechanical parts are guaranteed for 5 years, electrical parts and vulnerable parts are guaranteed for 1 year. 2. All parts on forming table are easy to access for maintenance. 3. All parts under forming table are lubricated by oil bath. Oil should be changed every 4-6 months with specified oil. |
1. Production output up to86,400 cups per shift (8 hours), up to 6.6 million cups per month (3 shifts). 2. Percentage of pass is higher than 99% under normal production. 3. One operator can handle several machines at the same time. |
Mechanical Quality Guarantee
Production Efficiency
Mechanical Behavior
NEWTOP-168S is suitable for producing 5-16oz espresso cups.
NEWTOP-168S coffee paper glass cup forming machine is an efficient, intelligent and environmentally friendly paper cup forming machine. This machine is good for making 5-16oz paper cups in the carton cup machinery, and the production speed can reach up to 180pcs/min.It adopts digital control mode and uses servo motor to control the paper cup forming process with high precision to achieve fast, accurate and stable paper cup forming effect. The control part integrates various techniques such as Ethernet real-time control technology,distributed clock mechanism, electronic cam technology and common DC bus to control efficiently stably and precisely. New Debao is the leader in the glass cup making machinery industry. Combined with digital construction, it has opened up a new development path for China's paper cup corporation machinery industry!
|
NEWTOP-168S |
|
|
Weight: |
3400 kg |
|
Machine encasement dimensions: |
3100 x 1600 x 2100mm (collection table 1230 x 610 x 1900mm) |
|
Connecting power: |
Three-phase 380V, 26KW |
|
Compressed air: |
0.6-0.8MPa, 0.5m³/min |
|
Production capacity: |
160 pcs/min |
|
Paper types: |
Single PE/Double PE/PLA |
|
Paper thickness: |
0.295-0.445mm |
|
Product range: |
(D1) ф60-95mm (H) 50-135mm (D2) ф40-75mm (h) 5-12mm |
|
Visual inspection system: |
○ |
|
Bottom heating: |
Assembly● |
|
Long term magazine: |
○ |
|
Control panel: |
7 inches |
